Construction year: 1914
Numbering locomotives: 16000 - 16067
Coupled on locomotives: Type 72, Type 90
Number of axles ( 2 Bogies ): 4
Wheel diameter: 1000 mm
Axle shaft dimensions
Diameter: 115 mm
Length: 200 mm
Water content: 16,000 m³
Coal content: 5,000 en 7,000 ton
Weight empty tender
Axle 1: 10,250 ton
Axle 2: 10,250 ton
Axle 3: 10,250 ton
Axle 4: 10,250 ton
Total: 41,400 en 43,400 ton
Weight empty tender: 20,400 ton
